condiment filling machine
High-Precision Filling Solutions for Sauces, Pastes, and Seasonings
What Is a Condiment Filling Machine?
The Condiment Filling Machine is designed for precise filling of sauces, pastes, and viscous liquids such as ketchup, soy sauce, chili sauce, and salad dressings. Using a piston or servo system, it delivers accurate volume control and consistent quality with minimal waste. All contact parts are made of food-grade stainless steel. Optional bottle feeding, capping, and labeling modules make it suitable for both small and large condiment production lines.
Product Applications
A. High-Viscosity Products
Chili Sauce (With/Without Particles)
Peanut Butter
Sesame Paste
Jam
B. Medium-Viscosity Sauces
Salad Dressing
Mayonnaise
Barbecue Sauce
Ketchup
C. Liquid Condiments
Soy Sauce
Vinegar
Edible Oil
Cooking Wine
Machine Advantages
Suitable for multi-viscosity products
Accurate and consistent filling
Food-grade contact parts
Modular design
Easy maintenance & CIP cleaning
Sauce Filler Salient Features
- Schneider servo system-regulated, variable-rate filling.
- Easy-to-use Schneider PLC-integrated digital control.
- Easy changeover and maintenance on the hot sauce bottling machine.
- ISO-9001-certified manufacturing, & GMP standard stainless steel.
- Bottom-up filling, bottleneck location, touchscreen controls volume; servos control filling pistons, & individual piston adjustment.
- Stainless steel frames protect the filling zone,
- Double, treble, and more sauce bottle filling digital control. To prevent foaming. nozzles may match liquid levels above or below the bottle opening.
- The hot sauce bottle filling machine features a three-step-filling to prevent bubbling and spilling.
Solution Configurations
1）Semi-Automatic Filling Line
Suitable for small factories and entrepreneursIncludes: Filling machine + Capping machine + Labeling machine
2）Automatic Piston Filling Line
Suitable for medium to large production lines
Includes: Mixer → Heating and Insulation → Filling → Capping → Labeling → Shrink Wrapping
| Project Name: Automatic Piston / Flowmeter Filling Machine | Jam and Sauce Products | |||
| Bottle Material | Bottle Shape | Filling Range | Filling Heads | Production Capacity |
| PET / PP / PE / Glass / Metal | Round / Square / Unique Shape | 0.2L-6L | 4-80 | 1000-20000bph |
| Filling Valve | Each filling valve is controled by servo motor ,realizing segmented high-and low-speed control ; vacuum resorption devices without leakage. | |||
| Cap Closing Method | Applicability for both crowning and capping, mechanical instant sealing or servo controlled sealing | |||
| Bottle Components | Rapid replacement without tools, such as star wheels for bottle infeed and outfeed, and bottleneck clamps | |||
| Filling Precision | Limit deviation: ±2-3g Standard deviation: 1.5 | |||
| User Ambient Conditions | Temperature: 10~40℃ Humidity: No dew | |||
| User Electrical Supply Specification | Voltage: 380V±5% 3phase Frequency: 50HZ±1% | |||
Soy Sauce / Vinegar Filling Machine
Soy sauce / vinegar filling machine is suitable for all kinds of vinegar, soy sauce, sauce etc. This soy sauce / vinegar filling machine apply electronic measuring mode and special liquid component to realize low foam volumetric filling and can rea…
Linear Type Daily Chemical Product Filling Machine
The Sauce Filling Machine is designed for filling high-viscosity materials such as chili sauce, tomato paste, peanut butter, sesame paste, bean paste, and jam. It uses a piston or screw pump metering system to ensure accurate, drip-free filling without stringing. All contact parts are made of food-grade stainless steel, meeting hygiene standards. The machine can be integrated with mixing, heating, capping, labeling, and packaging systems to form a complete production line — ideal for the food, condiment, and daily chemical industries.
Edible Oil Filling Machine
The Edible Oil Filling Machine is specially designed for quantitative filling of various vegetable oils such as peanut oil, olive oil, soybean oil, rapeseed oil, palm oil, and sunflower oil. It adopts a high-precision flowmeter or piston system to ensure accurate, fast, and drip-free filling. The machine features a compact structure, adjustable filling volume, and easy operation. All contact parts are made of food-grade stainless steel, meeting strict hygiene standards. It can be integrated with capping, labeling, and packaging systems to form a fully automatic oil filling production line, widely used in the edible oil industry.
Why Choose Sauce Filling Machine From NewPeak
√ High Filling Accuracy
With constant piston strokes, the advanced servo system controls filing volume. The piston’s adjustable mechanism is inteligently designed for accuracy.
√ Advanced Servo Drive system
An effective servo drive controls the fundamental filling structure in our series volumetric filling system for stablity and precise placement. The filling piston’s vertical action saves long-term energy and reduces automatic sauce filling machine load.
√ Tool-Free Easy Adjustment
PlC modifications don’t usually need specific equipment, although doing it yourself may improve workflow. Its accurate servo control design allows sauces of varying densities to be poured into bottle openings, necks, or surfaces.
√ Flexible and Highly Adaptable
An automatic servo sauce filling equipment may be designed and used in various industries,including food, pharmaceuticals,chemicals, cosmetics,etc.
