High Viscosity Sauce Filling Solution
Precision Filling for Thick and Chunky Sauces — Combining Efficiency and Hygiene
This solution is specially designed for high-viscosity and particle-containing sauces such as chili paste, ketchup, peanut butter, jam, and salad dressing. Equipped with a servo-driven piston or screw pump system, it ensures stable filling without dripping or stringing, meets food-grade hygiene standards, and supports automatic cleaning and multiple bottle size options.
Product Features
High-Precision Filling
Servo-driven piston or pump system ensures accurate volume control and consistent filling for each bottle.
High-Precision Filling
Servo-driven piston or pump system ensures accurate volume control and consistent filling for each bottle.
Flexible Customization
Available in 2–12 filling heads and customizable for different bottle sizes and production capacities; compatible with capping, labeling, and packaging systems.
Compact & User-Friendly
Compact modular design saves space, simplifies maintenance, and requires minimal operator training.
Watch Sauce Filling Machine in Action
Want to see more? Send us your inquiry and get access to complete video cases from real customer production lines worldwide.
Product Paramenters
Model | RCGF14-12-5 | RCGF16-16-5 | RCGF24-24-8 | RCGF32-32-8 | RCGF40-40-12 | RGF60-60-15 |
Capacity(for 500ml) | 2000BPH | 4000BPH | 8000-10000BPH | 12000-15000BPH | 16000-18000BPH | 24000BPH |
Suitable bottle shapes | circular or square | |||||
Bottle diameter(mm) | Dia50-Dia115mm | |||||
Bottle height (mm) | 160-320mm | |||||
Filling type | Overflow filinig type /Hot filling | |||||
Function | Rinsing filling capping | |||||
Rinsing pressure | >0.06Mpa <0.2Mpa | |||||
Application | Juice / Tea drinks / Milk Beverage | |||||
Total power (KW) | 4.4kw | 4.4kw | 4.4kw | 5.2kw | 6.2kw | 7.8kw |
Overall dimensions | 2.3*1.9m | 2.5*1.9m | 2.8*2.15m | 3.1*2.5m | 3.8*2.8m | 4.5*3.3m |
Height | 2.3m | 2.5m | 2.5m | 2.5m | 2.5m | 2.6m |
Weight(kg) | 3500kg | 5200kg | 7000kg | 9500kg | 10500kg | 12000kg |
