Advanced Isobaric Filling Machine for Carbonated Beverages
The carbonated drink production line is specially designed for producing carbonated beverages such as cola, soda water, sparkling juice, and flavored soft drinks. The line adopts advanced isobaric filling technology, integrating bottle rinsing, filling, capping, labeling, and packaging into one fully automatic process. It ensures stable performance, uniform carbonation, and consistent taste in every bottle.
Isobaric Filling Machine
The beer filling machine is specially designed for bottled, canned, and PET-packaged beer.
It adopts isobaric or vacuum filling technology to maintain uniform carbonation and precise liquid levels, ensuring fresh taste.
With a well-designed structure, smooth bottle handling, easy operation, and easy cleaning, it meets food hygiene standards.
Multi-head configurations are available to suit both craft breweries and large-scale industrial beer production lines.
Carbonated Beverage Filling Machine Specifications
| Technical parameter : carbonated beverage production line | ||||||
| Model | DCGF14-12-5 | DCGF16-16-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 | DCGF40-40-12 |
| Capacity(for 500ml) | 2000-3000 | 3000-4000 | 4000-5000 | 8000-9000 | 11000-12000 | 13000-15000 |
| Suitable bottle shapes | circular or square | |||||
| Bottle diameter(mm) | Dia50-Dia115mm | |||||
| Bottle height (mm) | 160-320mm | |||||
| Compressor air | 0.3-0.7Mpa | |||||
| Washing meidium | Aseptic water | |||||
| Rinsing pressure | >0.06Mpa <0.2Mpa | |||||
| Application | carbonated beverage production line | |||||
| Total power (KW) | 4.4kw | 4.8kw | 5.2kw | 6.2kw | 7.5kw | 8.2kw |
| Overall dimensions | 2.5*1.9m | 2.7*1.9m | 2.8*2.15m | 3.1*2.5m | 3.8*2.8m | 4.5*3.3m |
| Height | 2.3m | 2.5m | 2.5m | 2.5m | 2.5m | 2.6m |
| Weight(kg) | 3000kg | 4000kg | 4500kg | 6000kg | 8500kg | 10000kg |
Beer Filling Machine Specifications
Water Treatment System
Water Treatment System
Mashing & Blending System
Performs wort mashing, beer blending, and storage to control flavor and alcohol content.
Isobaric Filling Machine
Uses isobaric or vacuum filling technology for accurate liquid levels and stable carbonation.
Labeling Machine
Automatically applies labels to various bottle shapes.
Packaging System
Includes shrink wrapping and carton packing for efficient final packaging.
Conveyor System
Connects all equipment to enable smooth automatic conveying and synchronization.
